Lukud väravatele – Elektriline servalukk

Kaitse sissetungi eest.
Sertifitseeritud kuni turvaklassini 6 vastavalt Euroopa standardile EN 14846.

Korrosioonikindlus
Spetsiaalne epoksüüdpulbervärv tagab kõrge ilmastikukindluse välistingimustes või väga korrosiivsetes keskkondades (nt merealadel) paigaldamisel.

Sulgeb automaatselt.
Booster Plus mooduli ja “avamiskäsu ajastuse funktsiooni” režiimis sulgub jalakäijate värav/sissepääsuuks automaatselt, kui keegi kasutaja määratud aja jooksul sisse ei sisene.

Valmistatud Itaalias.
Toode vastab Euroopa standardite kõrgeimatele nõuetele, et tagada Itaalias valmistatud kvaliteedi tipptase.

Door status always under control.
The Booster Plus module has an indicator (which may be installed in the home if desired) which lights up every time the door/gate is not securely closed (door status signal).

Silent opening.
The reloading system guarantees silent operation as the lock is being opened, more than traditional electric locks.

Immediate, guaranteed closing over time.
The rotary hook deadbolt ensures immediate engagement of the floor striker, limiting rebound.
Self-adjustable floor striker helps correct any slight change in position of the door/gate which may occur over the years, ensuring the lock continues to work properly over time.

OTHER FEATURES

Managing flow through accesses.
“Hold open” function which prevents the entrance door/gate from closing, available in two versions:
– Electric: the Booster Plus module keeps the door/gate open at all times until the function is deactivated (from the home).
– Mechanical: the button on the lock (fitted on certain models) can be blocked by the key, leaving the door/gate always open until it is released.
Should the remote control malfunction, the driveway gate can still be opened:
thanks to the micro switch, the automatic gate can be opened manually (with keys) and directly from the lock without having to install a second lock.
Lock can always be opened, even with a drop in voltage.
When voltage is below the minimum rate (12V), the electric lock will always work.

TECHNICAL FEATURES

Certified up to Security grade 6 according to European standard EN 14846, guaranteed by the rotary hook deadbolt in extruded aluminium (patented) which provides resistance to tensile strength of up to 2000 kg (the standard covers a maximum of 1000 kg).
Protective steel casing to make it difficult to access the internal lock parts when the door/gate is closed.
The reloading system guarantees silent operation as the lock is being opened, more than traditional electric locks.
Metal striker with stainless steel “swinging pin”. Self-adjustable floor striker helps correct any slight change in position of the door/gate which may occur over the years
The rotary hook deadbolt ensures immediate engagement of the floor striker
The lock is easily interchangeable with other locks on the market as it uses the same holes.
Backset adjustable from 50mm to 80mm
Non-handed lock
12 V ac CE
Current absorption 3A
Reversibility and backset variable from 50 to 80 mm
High resistance to corrosion (240 hours in salt spray)

OPERATION MODES

Lukku saab hallata kahel viisil (avatud hoidmise funktsioon):
elektriline: Booster Plus moodul (kaugjuhtimisega) hoiab ukse/värava eelnevalt kindlaksmääratud aja jooksul kogu aeg lahti;
mehaaniline: luku nuppu (paigaldatud teatud mudelitel) saab võtmega blokeerida, jättes ukse/värava alati avatuks;
Booster Plus moodulil on indikaator, mis süttib iga kord, kui uks/värav pole kindlalt suletud;
Booster Plus moodul võimaldab teil seadistada luku automaatse sulgemise ajastuse;
Booster Plus moodul käivitab luku isegi siis, kui pinge on alla miinimumi (12 V);
Mikrolüliti võimaldab teil automaatse värava otse lukust avada.
