– Night locking; bolt extends 20 mm and the bolt is fixed. The handle does not open the lock.
– Day locking; the bolt extends 14 mm and the handle opens the lock. The changeover from night to day can be selected electrically and mechanically.
– The bolt retracts completely inside the housing against the opening impulse, allowing the door to be opened by pushing or pulling.
ABLOY 8904 TECHNICAL SPECIFICATION
- Operating voltage 24 VDC. ± 15%
- Maximum current 0.3 A
- Adjustable delay 1…20 sec.
- Temperature -20°C…+60°C
- 20 mm ledger outlet (8904)
- 14 mm (8910)
- Distance from the front strip to the middle of the cylinder is 50 mm
- Front bar 32 mm
- Rod 8 mm
- Cylinders oval Scandinavian type or Finnish type
- Locking bar 4692 / 4693
- Cable EA212 (8904) (not included)
- EA210 / EA211 (8910)
