Functionality of ABLOY EL650:
- The transom retracts into the housing and exits from the motor.
- The lock has an integrated door contact which prevents the bolt from escaping until the door is closed.
- ABLOY EL650 lock is microprocessor controlled, which increases the level of security.
- ABLOY EL650 can be set to operate in:
- One: closed and open position modes.
- Together with the EL412 or 8329 locks: High security, closed and open position modes.
- ABLOY EL650 is used as an additional high-security lock. Typical applications
- Gates and entrance doors of industrial buildings, shopping centers, office buildings, etc.
- Ideal solution for electric locking of sliding doors.
- Compatible with door automatics.
ABLOY EL650 TECHNICAL SPECIFICATION
- Operating voltage 24 VDC. ± 15%
- Maximum current 0.8 A
- Temperature -20°C…+60°C
- Programmable delay 1…255 sec.
- Ledger outlet 22 mm
- Distance from the surface of the front strip to the middle of the cylinder 25, 35 mm
- Front strip 25 mm (standard)
32 mm (spare part) - Cylinder EL650: Scandinavian oval type
EL651: Finnish type (CY065) - Locking strip EA300
Flat bar and separate magnet (spare part) - Cable EA215 (not included)
- Connection cable
EL650> EL412 EA203
EL650 > 8329 EA204
