Intercom systems – convenience and safety of everyday use
This system will work well in multi-apartment buildings, apartment blocks or blocks of flats, as well as in companies and other types of properties, to which access should be allowed to selected people, and at the same time limited to unauthorized persons. This is a convenient and safe solution – there is no need to carry a key to the entrance door, because you can easily open it with a code generated for each apartment or connect to a specific apartment by selecting the appropriate combination of numbers. What’s more, the staircase intercom looks aesthetically pleasing, so it will work perfectly in modern construction. It is worth noting that the device can service up to 255 apartments.
Innovative intercom with proximity reader – features
We offer panels equipped with a number of advanced functions. This is not only their adaptation to the needs of people with disabilities, such as the option of automatic or remote control, but also the possibility of introducing individual configurations, adapting the device to the specifics of the premises, for example a hotel and handling proximity key fobs. When it comes to Aco products, the dimensions of the intercoms are 206 mm x 88 mm. Their installation, depending on the choice of frame, can be made flush or surface-mounted. Thanks to the use of high-quality materials and modern technology, the device will remain efficient for years, providing residents with the comfort of everyday use. This is a solution that many people responsible for the design of residential buildings, offices and accommodation facilities have already decided on.
We invite you to purchase intercoms with a proximity reader !
Index | CDNP7ACC (G2) ST |
---|---|
Description | Digital intercom with code lock and proximity reader |
Execution | Powder coated aluminum alloy housing Flat front housing flush with the mounting frame Additional rear plastic housing covering the electronics Black display, white keyboard backlight |
Available language variants | PL-EN-DE-FR PL-EN-DE-SV EN-LT-IT-HU UA-EN-DE-PL |
Available colors | Steel (ST) |
Modules | Combination lock – individual four-digit opening code for each premises ACC – Unique 125kHz proximity key fob reader |
Max. number of subscribers | 255 premises |
Display | LCD (heated) |
Installation method | Depending on the frame selection: – flush-mounted – surface-mounted |
Dimensions (mm) | 206x88x29.3 |
Installation type | Digital: 2 wire – P system or UTP cat. 5e/6 twisted pair – PV system |
Line length | Max 1000m |
Power supply | 15V DC / 200mA or 12V ± 0.5V AC |
Power consumption in standby mode | ~1W |
Exits | 2 x screw terminals “ELOCK”: connection of a traditional electric strike (max. 1A) or reversible (max. 0.5A) or CDN-PK relay module (max. 5A) 2 x screw terminals: connection of the audio signal: “LINE+” and “LINE- (GND)” 2 x screw terminals: connection of the second relay output (OUTPUT): “N” and “NO” (max. 2A,30VDC) |
Entrances | 4 x screw terminals: power supply connection: constant “+DC” and “GND” or variable “AC” and “AC” 1 x “INPUT” screw terminal: connection of a normally open button (NO) 1 x screw terminal: connection of the audio signal from preceding control panel (“ML+”) 2 x “EXTMOD” socket for connecting optional modules |
Facilities for people with disabilities | Illuminated keyboard buttons (optionally with Braille) Acoustic and optical signalling Automatic or remote door opening Connection of additional acoustic/light ringing devices |
Characteristics | Resistant to vandalism and weather (-20 to 50°C, IK07, IP42) Easy assembly Supports Master/Slave systems Universal Master and Slave design Available codes: 255 tenant, 5 admin, 1 installer Supports up to 6144 key fobs Adjustable conversation time (40-120 sec) Supports electric strikes and electromagnetic locks Home automation functions Programming from control panel and PC Free software available |
