The COMO-PRO series is a continuation and at the same time the next generation of the well-known panels of the FAMILIO-PRO series. It is not only a name change, but also a completely new construction of the intercom control electronics to ensure even greater reliability and capabilities of the device. The third generation of these panels support for larger (longer) installations, a larger number of subscribers, remote management of devices (from anywhere in the system), software update and full management of proximity tags with a key fob “master” and “super master”. The panel will be constantly developed, and thanks to software updates, all new functionalities and capabilities of the panel will also be available for people who have already bought a product. The video panel is equipped with a color camera with an adjustable position of the direction of observation and LED lighting, a reader of proximity key fobs, access control and 1 backlit button and description field.
Parameter | Description |
---|---|
Index | COMO-PRO-V1 |
Description | Digital video door entry system for PRO system, with proximity key fob reader and 1 call button |
Material | 2mm thick flat front panel and stainless steel brushed buttons |
Modules |
|
Max. phones | 1 |
Mounting |
|
Dimensions (mm) | Panel: 286×90 Flush box: 268×73×32 |
Installation type | Digital PRO system (cat. 5e or 6) |
Line length | Max. 1000 m |
Power supply | 15V DC / 400mA |
Stand-by consumption | ~ 2.5W |
Outputs |
|
Inputs |
|
Features for disabled |
|
Attributes |
|
New (3rd gen) features |
|
