CP-Z 2H EMBEDDED
| Maximum Wiegand Line Length (m) | 100 |
| Voltage | 8-18 DC |
| Current consumption (mA) | 35 year |
| Visual indication | 1 x red LED |
| Backlight | Solid red LEDs (optional) |
| External control of LEDs and buzzer | No |
| Working temperature (° C) | -30 … + 85 |
| Body material | Polyamide |
| Overall dimensions, mm) | D26 x 22 |
€42.82 inc VAT
Price valid only in the e-shop
2 People watching this product now!
Local Pick up (Tuuliku Tee 4)
0€
Parcel Machines (Itella Estonia)
2.99€
Parcel Machines (DPD Estonia)
6.10€
Payment Methods:
Compact built-in RFID reader CP-Z 2H for use in networked and stand-alone access control systems. The built-in CP-Z 2H reader supports HID ProxCard II 125 kHz keys and connects to the controller via the Wiegand-26 protocol.
The built-in reader CP-Z 2H is made of mechanically strong and fire-resistant material and replicates the iButton for contact keys DS1990 / DS1996. This allows using the built-in CP-Z 2H reader in ACS products instead of iButton contactors for contact keys without any design changes or installation difficulties. This gives you the following benefits:
- Additional services and functionality of RFID technology.
- Advantages of contactless door opening (without removing the key from your pocket or wallet).
- A wide range of RFID keys of various shapes and colors, as well as the ability to apply a unique logo to the keys.
| goal | ACS reader |
| Working frequency | 125 kHz |
| Key types | RFID (proximity) |
| Standard reader | HID ProxCard II |
| Reading protocol | Wigan-26 |
| RFID Reading Range (cm) | 2-6 |
| Keyboard | No |
| Vandal-proof housing | Yes |
| Waterproof dust cover | Yes |
| Key copy protection | No |
