Digital doorphone INSPIRO 9+

Index
INSPIRO 9+ (G2) (Master/Slave unit)
INSPIRO 9+ (Master unit)
INSPIRO 9S+ (Slave unit)

Description
Digital door intercom with keypad access control and a small description list

Execution
2 mm flat front panel with backlit brushed stainless steel buttons

Available language versions

• PL-EN-DE-FR

• PL-EN-DE-SV

• EN-LT-IT-HU

Modules

• 5N – small module with illuminated description list

• Keypad lock – individual 4-digit unlock code per room

Display
Heated LCD

Maximum number of users
Up to 1020 rooms

Installation method
Flush-mounted
(optional mounting box: INS-PM NT)

Dimensions (mm)

• Panel: 111 × 290

• Description field: 73 × 39

• Flush mounting box: 92 × 271 × 31.5

Installation type
Digital: 2 wires

Line length
Max. 1000 m

Power supply
15 V DC / 174 mA or 12 V ± 0.5 V AC

Power consumption in standby mode
~0.7 W

Outputs

• 2 × screw terminals “ELOCK”: for connecting a traditional electric strike (max 1 A), fail-safe lock (max 0.5 A), or CDN-PK relay module (max 5 A)

• 2 × screw terminals: for audio signal – “LINE+” and “LINE– (GND)”

• 2 × screw terminals: for second relay output – “N” and “NO” (max 2 A, 30 VDC) – Master unit only

Inputs

• 4 × screw terminals: power connection – “+DC” and “GND”

• 1 × screw terminal “INPUT”: for a normally open (NO) button – activated by shorting to system GND (e.g., external door release button)

• 1 × screw terminal: audio signal from previous panel (Master Line) – “ML+” (Slave only)

• 2 × “EXTMOD” sockets for optional modules

Accessibility features

• Backlit keypad buttons, optionally compatible with Braille

• Acoustic and optical signaling for panel functions

• Automatic or remote door unlocking (via button) without answering a call

• Option to connect an additional acoustic or optical signal device indoors (CDN-U)

Features

• Weather- and vandal-resistant

• Configurable 6-digit apartment numbers

• 4 separate code tables

• Available codes:

  • 1020 tenant codes (4-digit)

  • 5 administrator codes (4- or 6-digit)

  • 1 installer code (8-digit)

• Programmable entry on the main screen (up to 30 characters)

• Adjustable maximum call time (40–120 seconds)

• Support for a wide range of expansion modules to enhance system functionality

• Support for multi-input Master/Slave/Multimaster systems

• Optional SW4S-DIN module required for 1020 rooms

• Unlocking electric strike or additional relay output without an active call (via CDN-I/O)

• Home automation: control of external devices such as gates, barriers, lighting, and shutters via keypad, key fob, or receiver. Also possible without an active connection:

  • Gate opening – triple key press

  • External device control (via CDN-I/O module) – triple key press

  • Per-room access permissions for controlling external devices

• Multiple receivers can be assigned the same number using active receivers

• Extensive per-room configuration options

• Intuitive and convenient operation and configuration

• Corridor unlocking function

• Ability to change call number ranges and groups

• Up to 8 preset numbers that can be dialed without voice communication

• Automatic door opening function per room

• Concierge function

• Ability to display a custom message (up to 6 characters) on screen during concierge call forwarding

• Adjustable number of door releases during a call (1–3)

• Support for various types of electric and electromagnetic locks

• 8 priority extension numbers with individual call settings

• Call forwarding to extension numbers

• PC programming without external power supply

• Programming via control panel or PC using USB cable

• Free configuration software available in the “Downloads” section

• Compatible with all digital devices from the following groups: CDN, Inspiro, and Familio P/PV
