Electric resistor – S12R

Hartte series S – Openable

Openable electrical response Hartte S is used for remote opening of metal,

wooden or aluminum doors. It shall apply to access control systems

intercoms, and card reader systems. The electrical response has a symmetrical design and an adjustable latch.

If there is no power – the doors are open.

Main part:

working mode (NO – normally open)
dimensions (width 21mm, height 75.4mm, depth 28mm)
working temperature -40 to +50 C degrees
mechanical strength – inlet resistance 3430 N (350 kg)
mechanical strength – opening cycles 200,000
left and
adjustable latch on the right door up to 4mm
