ELTIS PS2-CS2 POWER SUPPLY
ELTS PS2-CS2 power supply. It is intended for the power supply of ELTIS audio on-door speakerphones of the DP420, DP400 series. It can be used with DP400 series video on-door speakerphones, when using separate stabilized + 12V power supplies for the video path equipment (video cameras of the outdoor panel, video splitters, and video switches).
PS2-CS2 provides:
- the power supply of the call unit, exit buttons, switches, audio tubes (˜15V);
- the switched power supply of the e / m lock (+ 12V) with an electromechanical relay for controlling the lock and demagnetizing circuit;
- connection of an exit button for switching power supply control.
The power supply is protected by fuses on the input and output circuits, as well as a thermal fuse to protect against overheating of the transformer.
Supplied with pre-installed 220V power cord and spare fuses. Switching – screw terminal blocks. The case has holes for mounting, as well as a latch for mounting on a DIN rail.
Price valid only in the e-shop
Local Pick up (Tuuliku Tee 4)
Parcel Machines (Itella Estonia)
2.99€
Parcel Machines (DPD Estonia)
6.10€
Payment Methods:
SPECIFICATIONS
| Output voltages when operating from a power frequency AC mains and rated voltage 220 (+10% – 15%) V: | |
| Between outputs Y1, Y2, at a load current of 0.3A | ~ 15V (± 10%) |
| Between the outputs ZNC (ZNO) and ZC, at a load current of 0.6A | + 12V (± 10%) |
| Load current connected to contacts ZNC (ZNO) and ZC, no more | A 0.6 |
| Overall dimensions, mm, no more | 150х95х65 |
| Weight, kg, no more | 0.76 |
| Operating temperature range | (-10…+40)°С |
| Relative humidity no more | 90% |
