Laskomex EC-2502AR electronic cassette

EC-2502 electronic cassette is a microprocessor device, which control work of the whole doorphone system. Older versions of digital doorphones used two types of electronic cassettes – to the main entrance and to the subordinate one. CD-2502 doorphone uses one kind of electronic cassette, in which the installer defines what type of entrance it will support.

Electronic cassette is supplied from the two- winding AC adapter. One of the windings is used to power the cassette and an outdoor panel while the second one to power a door release. In the electronic cassette, there are potentiometers to adjust strengthening of a speaker, microphone and line balance.

Using jumpers, one may configure in electronic cassette the type of blocking device (door release or electromagnetic lock). In electromagnetic locks (jumpers), there is often the phenomenon of residual magnetism, which results in difficulties with opening doors (gates), so the electronic cassette is equipped with a system for eliminating this undesirable phenomenon. Enabling the mechanism of jumper demagnetization in situation when a door release is used may cause its improper work!

The cassette includes INIT and RESET buttons, used among other things to restore the default settings of doorphone. Electronic cassette EC-2502 may co-work with a battery, which ensures proper work of the doorphone system in case of power failure in the power grid.

Electronic cassette EC-2502 may be used as a counterpart for the following types of electronic cassettes applied in the older models: EC-2200, EC-2200/U, EC-2200/H, EC-2200/INT, EC-2500/S , EC-2500/R, EC-2500/U, EC-2500/H, EC-2501, EC-2501/U, EC-2501/H
