Specialized Ethernet/RS-485 converter x2

• Work with local software and cloud services of the access control system via the HTTP protocol
  (does not require additional network configuration)
• Access to devices on the RS-485 bus via Ethernet
• Two RS-485 ports (one galvanically isolated up to 1000 volts)
• TCP/IP protocol operation
• Connection setup modes: “client” and/or “server”
• Support for NVT ( Network Virtual Terminal ) protocol
• Online Commander – for web browser control of network controllers connected to Z-397 converters (mod. WEB)
• Availability of drivers for most operating systems ( virtual COM port )
• Configuration via USB port (Flash Disk), as well as remotely via TELNET protocol
• Firmware update
• Mechanical lock for configuration changes and firmware updates
• RS-485 packet integrity monitoring during transmission
• Indication of operating modes

Technical specifications:

• Ehternet: Ethernet RJ45 interface (10/100BASE-T, Ethernet II and IEEE 802.3)
• Protocols IPv4, ARP, TCP, TELNET, ICMP, UDP, DHCP, HTTP, NVT
• Number of RS-485 lines: 2
• Speed: up to 115200 bps
• Galvanic isolation of 1 – 1 kV line
• Galvanic isolation of line 2 – no
• Connector: USB Type B
• Version: USB 2.0
• Mode: Full-Speed ​​Klass – Mass-storage device
• Power supply voltage: 8-18V DC or 7-14V AC
• Current consumption: no more than 100mA (at 12V DC)
• Operating temperature: +5°С +40°С
• Humidity (non-condensing): 5%…95%
• Case material: ABS plastic
• Weight: 100 g
• Overall dimensions (mm): 100x85x30
