VIDEO PANEL SELECTION BOX - 4 INPUTS, RJ45 + DIN RAIL MOUNTING, WHITE find out about the price
Back to products
CAN SEPARATION BOX – 2 OUTPUTS - RJ45, DIN RAIL MOUNTING, WHITE find out about the price

VIDEO AMPLIFIER – 4 OUTPUTS – RJ45, DIN RAIL MOUNTING, WHITE

SKU: DVA.4PS02.ELW

find out about the price

Price valid only in the e-shop

3 People watching this product now!
Compare

Local Pick up (Tuuliku Tee 4)

0€

Parcel Machines (Itella Estonia)

2.99€

Parcel Machines (DPD Estonia)

6.10€

Payment Methods:

Video signal recovery for long distances | Complex systems | DIN rail mounting

The differential video amplifier with 4 outputs can have multiple uses, as follows:
1.    Recovery of the video signal in installations with cable lengths exceeding 250 m.
2.    Connection of more than 2 video terminals in the same residence.
3.    Separation of the video signal in 2, 3 or 4 ramifications, in the case of buildings with multiple sections or residential centers with
multiple buildings.
The case is made of ABS and mounting can be done on DIN rail or on surface.

Weight 0.4 kg
Dimensions 13 × 14 × 7.3 cm
Brand

Model

DVA.4PS02.ELW
Technical features

DIN rail mounting, TH 35 X 15/ 35 x 7.5; DIN 46277-3, EN50022, IEC60715 standard or surface mounting
RJ45 connectors
Installation with UTP cat 5e (AWG 24) or UTP cat 6e (AWG 23) cables.
Operating voltage: 13.5 Vd.c., 2.5 Ad.c.
Range of operating temperatures: 0 … +45°C
Certification

The product is CE certified by OICPE – Certificate no. 707.
The product contains printed circuit boards certified in compliance with the UL flammability standard – Certificate no. E307311.
The product is manufactured under the ISO 9001:2008 quality management system and under the ISO 14001:2009 environment management system, certified by TÜV HESSEN – Certificates no. 73 100 4856, 73 104 4856.
