Audio/video digital call panel for IP system with repertory name facility, 4000 Series modular mounting
| Audio/Video | Audio/Video |
| Repertory name facility | Yes |
| Camera sensor/LED Type/Tiltening |
Wide angle camera with white light illumination LED’s |
| Wide Camera opt | Standard |
| Display/Backlight | Graphical 128x64px/Blue |
| Built-in proximity key reader | Yes 125Khz H4102 10000 Keys |
| Programming | Keypad/PC via VX IP Wizard |
| Interfaces | RS-485/WIEGAND |
| Plate type | Vandal resistant |
| Plate finishes | Brushed stainless steel |
| Keypad buttons | 15 |
| Mounting | Modular 4000 Series |
| Size | 2 modules |
| Speach board opt | Standard |
| Apartments/Users/Codes | 10000/10000/10000 |
| Access control | User code/Proximity key/User code + proximity key |
| Relay | 2 |
| Relay voltages | Max 24Vac/dc 2A |
| Relay contacts | Dry contacts / Capacitor discharge (12Vac/dc 1A max) |
| PTE input | Yes, 2 |
| TRD input | Yes |
| Working voltage | 12 Vdc |
| Working temperature | -10 +50°C |
