Camera |
Image Sensor |
1 / 2.39″ CMOS |
Image Size |
3200×1800 |
Electronic Shutter |
1/3s ~ 1 / 100000s |
Iris Type |
Fixed Iris |
Min. Illumination |
Color: 0.02 lux @F1.6, AGC ON; B&W: 0 lux with illumination on |
Lens Mount |
Motorized |
Day/Night |
Auto, Day, Night, Timing |
Wide Dynamic Range |
120dB |
BLC / HLC |
Yes |
Angle Adjustment |
Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360° |
Lens |
Focal Length |
2.8~12mm@F1.6 |
Field of View |
H: 108°~36°, V: 57°~20°, D: 129°~42° |
Image |
Digital NR |
Yes |
Image Settings |
ROI, Brightness, Contrast, Sharpness, Flip, Mirror, WDR, NR, etc. |
ROI |
Each ROI configurable independently |
Video |
Compression |
Main: H.265+/H.265/H.264+/H.264; Sub/Third: +MJPEG |
Resolution |
6MP, 4MP, 2K, 1080P, 720P, D1, VGA, 640×360, CIF, 480×240 |
Main Stream |
60Hz: up to 6MP@30fps; 50Hz: up to 6MP@25fps |
Sub Stream |
720P~CIF @ 30fps (60Hz) / 25fps (50Hz) |
Third Stream |
D1/480×240/CIF @ 30fps (60Hz) / 25fps (50Hz) |
Bit Rate |
64 Kbps ~ 8 Mbps |
Bit Rate Type |
VBR / CBR |
Audio |
Audio Interface |
1CH input, 1CH built-in MIC, 1CH output, 1CH built-in speaker |
Audio Compression |
G711A/U |
Network |
Interface |
RJ45 |
Remote Monitoring |
Web / NVR / NVMS2.X / Mobile APP |
Simultaneous Users |
Up to 6 |
Protocols |
UDP, DHCP, NTP, RTSP, RTP, RTMP, IPv4/6, HTTP, FTP, SNMP, 802.1x, etc. |
Storage |
Local Storage |
Micro SD card slot, up to 256GB |
Network Storage |
Remote network storage |
Smart Functions |
Smart Events |
Line crossing, region intrusion (object classification), abandoned/missing object |
Alarms |
Motion detection, SMD, SD error/full, IP conflict, video exception, audio alarm, light alarm |
Security |
Features |
Encryption (video, firmware, config), IP filtering, login lock, 802.1x, HTTP auth |
Supplement Light |
IR Range |
30~40m |
White Light Range |
30~40m |
General |
PoE |
Yes (IEEE802.3af) |
Ingress Protection |
IP66 |
Power Supply |
DC12V / PoE |
Power Consumption |
< 11W |
Dimensions |
Ø111.5 × 99.6 mm |
Weight |
Approx. 0.604KG ~ 0.62KG |
Installation |
Ceiling or wall mount |
Browser Support |
IE11 (plug-in), Chrome 89+, Edge 89+, Firefox 87+, Safari 14+ |
Operating Conditions |
-30°C ~ 60°C, < 95% RH |
Storage Conditions |
-30°C ~ 65°C, < 95% RH |
Certificates |
CE, FCC, RoHS, WEEE, REACH |
DORI Distance |
Detect |
66m (W) / 204m (T) |
Observe |
27m (W) / 82m (T) |
Recognize |
13m (W) / 41m (T) |
Identify |
7m (W) / 20m (T) |
