| Camera | |
| Image Sensor | 1/3″ CMOS |
| Image Size | 2560 × 1440 |
| Electronic Shutter | 1/1s ~ 1/100000s |
| Iris Type | Fixed Iris |
| Min. Illumination | 0.005 lux @F1.6, AGC ON; 0 lux with illumination on |
| Day/Night | ICR Auto Switch |
| S/N Ratio | ≥50 dB |
| Wide Dynamic Range | 120 dB |
| BLC / HLC | Yes / Yes |
| Digital NR | 3D DNR |
| Lens Mount | M12 |
| Focus | Fixed |
| Angle Adjustment | Pan: 0°~360°, Tilt: 0°~80°, Rotation: 0°~360° |
| Lens | |
| Focal Length | 2.8mm @F1.6 |
| Field of View | Horizontal: 94°, Diagonal: 115° |
| Image | |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Sharpness, Mirror, Flip, NR, etc. |
| ROI | Each ROI to be configured separately |
| Video | |
| Compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| H.265 Compression Standard | Main Profile@Level 4.1 High Tier |
| Resolution | 4MP, 3MP, 1080P, 720P, D1, VGA, CIF, 480×240 |
| Main Stream | 4MP/3MP/1080P/720P (60Hz: 1~30fps; 50Hz: 1~25fps) |
| Sub Stream | 720P/D1/VGA/CIF (60Hz: 1~30fps; 50Hz: 1~25fps) |
| Third Stream | D1/CIF/480×240 (60Hz: 1~30fps; 50Hz: 1~25fps) |
| Bit Rate | 64 Kbps ~ 6 Mbps |
| Bit Rate Type | VBR / CBR |
| Audio | |
| Audio Interface | 1CH audio input; 1CH built-in MIC |
| Audio Compression | G711A/U |
| Network | |
| Interface | RJ45 |
| Network Protocol | UDP, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, IPv4, IPv6, SMTP, FTP, 802.1x, SNMP, UPnP, HTTPS, HTTP POST, P2P, QoS |
| Remote Monitoring | Web browser, NVR, NVMS2.X, Mobile App |
| Simultaneous Users | Up to 6 users |
| Storage | |
| Local Storage | Micro SD card slot, up to 256GB |
| Network Storage | Supported |
| Smart Functions | |
| Smart Events | Line crossing, region intrusion (human/vehicle classification), abandoned/missing object |
| Alarms | Motion detection, SMD, SD error/full, IP conflict, network disconnection, video exception |
| Security | |
| Security Features | Encryption (video, firmware, configuration), HTTPS, login lock, IP filtering, 802.1x, HTTP auth |
| Supplement Light | |
| Smart Supplement Light | Yes |
| Range | White light: 40m, IR: 50m |
| General | |
| PoE | Yes (IEEE802.3af) |
| Ingress Protection | IP67 |
| Power Supply | DC12V / PoE |
| Power Consumption | < 6W |
| Dimensions | 167.6 × 75 × 74.6 mm |
| Weight | Approx. 0.45 kg |
| Installation | Ceiling or wall mount |
| Browser Support | Chrome 89+, Edge 89+, Firefox 87+, Safari 14+ |
| Operating Conditions | -30°C ~ 60°C, <95% RH (non-condensing) |
| Storage Conditions | -30°C ~ 65°C, <95% RH (non-condensing) |
| Certificates | CE, FCC, RoHS, WEEE, REACH |
| DORI Distance (2.8mm lens) | |
| Detect | 62m (203ft) |
| Observe | 25m (81ft) |
| Recognize | 12m (40ft) |
| Identify | 6m (20ft) |
