Eltis Code Panel KU18-1

System composition
code device KU18-1;
power supply IP-16-x (x – a model of power supply, depends on the type of lock used);
electromagnetic coil (type of lock is determined by the customer);
optional: door closer, casing for wall mounting.

Functions and service capabilities of the product
reading of pin-code typed on the keypad and comparing it with memorized one;
Reading TM-key and comparison with memorized one;
sound signals generation;
LED indication of operation and programming modes;
formation of a logical signal to control the electromagnetic lock of a given duration:
only when the pin code coincides with the one recorded in the memory;
only when the TM key overlaps with the one stored in the memory;
when pin code or key coincides;
when both the pin code and the key coincide (input in any order);
pressing the “Exit” button.
Keypad programming;
saving information in nonvolatile memory.
