Description
Key Features:
* Low price
* Installation and connection in 10 minutes
* Installation on the door 30-115 mm
* Installation of conventional locking mechanism
* Office / hotel mode
* Standalone / Network mode
* Work independently or as part of software Lock Commander
* Selection software HOTEL mode
* SDK integration hospitality software (PMS) specifications:
* Operating frequency: 125 kHz
* Reading ID: EM-Marine, HID ProxCard II TEMIC
* Number of keys / cards (max): 2024sht.
* Number of retained events (max): 2048sht.
* Built-in memory (EEPROM)
* Reading range: 2-4 cm
* Power consumption: 30mkA (idle)
* Power: 1,5 V X3 PCs. standard AAA
* Opening on one of the batteries: 50000-80000, depending on the battery
* Communication lines: Micro USB, RS485, Wiegand 26, RF, WiFi * optional
* Connections to external control panels: yes
* Sound / light indication: Signal, 3-color LED
* Adjustment of lock release: 0-220 c
* Set door thickness (mm): 30-70 or 70-115
* Center distance (handle cylinder), mm: 0.72, 85, 92
* Fits lock housing: European, DIN
* Operating temperature: + 5 ° C to + 40 ° C
* Case material: silumin, steel
* Dimensions pad (without handles) mm: 280x50x20
* Color: matte stainless steel
OFFICE mode-office locks can only be opened in card memory Castle. Electronic door lock can be opened from the outside with a beskontatnoy card or mechanical key, and the inside of the door just enough to push the handle. Function: Free-Feed blocking, “do not disturb”. When using specialized software, smart card locks open for filing at scheduled time and day of the week. Also, smart door locks can be transferred to the state for free passage scheduled on certain days of the week
HOTEL mode-electronic locks for hotels take into account all the functions of security and livelihoods of hotels / hotels / hostels / hostels / student campuses, etc. Castle Hotel elektronnyyEurolock EHT net is integrated under the control of any hotel software (PMS) available in the market
