Features:
- Stainless steel Panel with Elegant Style
- NO/COM Contact Output,Suitable for all kinds of Locks
- Dimensions: 90Lx35Wx20H(mm)
- Directly dry contact input, no external power supply
- 500000 Cycles tests.
- This door release exit button can be used for any access control application and is commonly used in offices, banks, gas stations, department stores and many more
Specifications：
- Dimensions: 90Lx35Wx20H(mm)
- Contact Area: <100ohm
- Material of Panel: SUS304 Stainless Steel
- Operating Temperature: -20℃~+50℃
- Wire color: White: NO/COM
- Current Standby: 20mA
- Output Contact: NO/COM
- Current Rating: 1A@12VDC(Max.)
- Waterproof Level: IP-68
- Weight: 0.07kg
Attention:
- Please buy the mounted back box separately.
Package:
- 1 x Exit Button
- 1 x English Manual
