GLASS & TOUCH design
Chemically toughened GLASS is the essential material used for manufacturing the Touch Line range of products, thus inducing a minimalistic
and timeless elegance. Apart from the minimalistic aesthetics, the chemically toughened glass also ensures other fundamental characteristics of the products: scratch and shock resistance, impermeability, lasting polished aspect and easy maintenance.
The use of backlighted TOUCH keys keeps in line with the current tendencies in design and technology, as far as the ease of use is concerned, through a universally recognized visual language, with intuitive graphic markings.
Through a solid and essentialized look, the extra 7” video terminal represents a stylish presence, which can be naturally integrated in any
The ELECTRA assembly solution of the extra 7” video terminal is original and efficient, resulting in a product with a slim appearance, but at the same time dust tight and easy to install.
Through the perfectly layered conjunction of the constructive elements, respectively the resistant ABS case and the 3 mm chemically toughened glass, doubled on the inside by the printed circuit board of the same dimension, results a robust product, only 20 mm thick, which is very easily mounted on any surface.
The simple truth is that one image is worth more than a thousand words. The extra 7” video terminal displays high definition images during the entire duration of the call, talk and monitoring.
The night vision is excellent, at a distance of 20 m, even when there is no street lighting.
The Touch keyboard is very representative, both through its universal minimalistic symbols, as well as through the visual signaling along the entire use time. The keys have different functions in stand-by and during use, a multifunctionality that brings further advantages to the users.
The interaction of the user with the terminal is minimal, as any function can be achieved with a single touch of the key.
Another very important characteristic of the Touch keys is that they do not get blocked, irrespective of the use frequency, which translates into long term reliability.
When the terminal is called, the key blinks.
The talk begins with a simple touch and continues completely hands-free, during maximum 2 min.
When the terminal is in stand-by mode, touching the key activates audio-video monitoring for 15 sec. Therefore, one can see and hear what goes on in front of the entrance at any time, also having available the option of bidirectional talk. Furthermore, the video monitoring can be done successively on multiple video cameras, as the ELECTRA video door phone system allows the connection of multiple additional cameras.
Also in stand-by mode, through a very simple procedure, the preferred ringtone can be selected from the 5 available options.
Access can be granted in any terminal mode – stand-by, call, talk or monitoring. The video image remains active 10 more seconds, for visual confirmation of the action’s completion.
In stand-by mode, the call duration can also be set, according to preferences: 1/2/3 calls or 1 min.
There are 7 available volume levels for the call and the talk, and the option of activating the silent mode call. Volume adjustments can be made during use, as well as in stand-by mode.
The silent mode is visually signaled by a red LED that is permanently on.
The auxiliary key can be used for controlling another automation: auto gate, garage door, outdoor lighting system. The ELECTRA video door phone system is fitted with direct connections for such an automation, feature which allows the installation to be upgraded with various additional devices.
The picture taking option has a very high contribution as far as safety and comfort are concerned. This function allows a complete record of all calls, as for every call made from the outdoor panel, a picture is automatically taken.
At the same time, the resident has the possibility to take additional pictures, at any time during the call, talk or monitoring, by simply touching the key. The memory capacity of the terminal is 100 images. When this limit is exceeded, the oldest images are automatically deleted in order to free space for the new ones.
The available menu allows:
- Visualizing and deleting the images.
- Setting the date and the time
- Adjusting the parameters of the video image: contrast, brightness and chrominance
Intercommunication with the parallel-connected terminals.
