MATRIX III RD-ALL
| iButton (1-Wire) maximum line length (m) | 15 |
| Maximum Wiegand Line Length (m) | 100 |
| Voltage | 8-18 DC |
| Current consumption (mA) | 135 |
| Bleeper | Buzzer |
| Visual indication | 1 x 2 color LED |
| External control of LEDs and buzzer | Yes |
| Working temperature (° C) | -30 … + 40 |
| Body material | ABS polymer |
| Overall dimensions, mm) | 115х75х22 |
€106.64 inc VAT
Price valid only in the e-shop
Local Pick up (Tuuliku Tee 4)
Parcel Machines (Itella Estonia)
2.99€
Parcel Machines (DPD Estonia)
6.10€
Payment Methods:
The RFID Matrix III RD-All reader is designed for use in online and offline access control systems, as well as in discount and payment systems.
The Matrix III RD-All reader has a flexible configuration that can be adapted to a specific task by changing the reader’s firmware using a PC. Direct connection to a PC is carried out via RS-232 protocol (distance not more than 5 m) or RS-485 protocol using Z-397 Guard USB / RS-485 adapter (distance not more than 1200 m).
The Matrix III RD-All Reader has an optional set of free SDK readers to make it easy to start your own applications.
| goal | ACS reader, Payment system |
| Working frequency | 125 kHz, 13.56 MHz |
| Key types | RFID (proximity) |
| Standard reader | EM Marine, HID ProxCard II, Mifare Classic 1K, Mifare Classic 4K, Mifare ID, Mifare Plus, Mifare PROX, Mifare Ultralight |
| Reading protocol | iButton (1-Wire), Wiegand-26, RS-232, RS-485 |
| RFID Reading Range (cm) | 4-10 |
| Keyboard | No |
| Vandal-proof housing | No |
| Waterproof dust cover | Yes |
| Key copy protection | No |
| Dimensions | 11.5 × 7.5 × 2.2 cm |
|---|---|
| Color |
Blue ,White |
