RFID Keyfob T5577 125Khz Model: IL-07T
IronLogic
Click to enlarge

RFID Keyfob Mifare 13.56MHz Model: IL-07M

Main characteristics:
  • Attractive appearance
  • Can’t make a copy
  • Encryption support
Two-color smart keyfob of the Mifare standard with a memory capacity of 1024 bytes. Small size, slim body, attractive appearance, choice of body colors. Iron ring for fastening. Iron carbine can be supplied. Overwriteable up to 100,000 cycles. Anti-collision support, data storage up to 10 years. The MIFARE classic family is the most common for contactless crypto-protected cards, operates in the 13.56 MHz range, is ISO 14443A compliant. Application, payment systems, access control systems, transport cards, discount systems, loyalty programs, etc.
Compare
Add to wishlist
SKU: IronLogic IL-07M Categories: ,
Description

Description

Specifications:

  • Chip type: Mifare S50, ISO14443A standard
  • Working frequency: 13.56 Mhz
  • Card type: Read / Write
  • Transaction time: 164 ms
  • Anti-collision support: Yes
  • Memory capacity: 1024 bytes, EEPROM
  • ID stamp: no
  • Material: ABS Possibility to apply logo Color (circle + frame): white + green, white + blue, yellow + green, yellow + blue
  • Working temperature: -30 ° С … + 50 ° С
  • Storage temperature: -40 ° С … + 75 ° С
  • Dimensions (mm): 37x30x3
