GLASS & TOUCH design
Chemically toughened GLASS is the essential material used for manufacturing the Touch Line range of products, thus inducing a minimalistic and
Apart from the minimalistic aesthetics, the chemically toughened glass also ensures other fundamental characteristics of the products: scratch and shock resistance, impermeability, lasting polished aspect and easy maintenance.
The use of backlighted TOUCH keys keeps in line with the current tendencies in design and technology, as far as the ease of use is concerned, through a universally recognized visual language, with intuitive graphic markings.
Through a solid and essentialized look, the smart+ audio terminal represents a stylish presence, which can be naturally integrated in any
Smart assembly | Easy installation
The ELECTRA assembly solution of the smart+ audio terminal is original and efficient, resulting in a product with a slim appearance, but at the same time dust tight and easy to install.
Through the perfectly layered conjunction of the constructive elements, respectively the resistant ABS case and the 3 mm chemically toughened glass, doubled on the inside by the printed circuit board of the same dimension, results in a robust product, only 22 mm thick, which is very easily mounted on any surface.
The Touch keyboard is very representative, both through its universal minimalistic symbols, as well as through the visual signaling along the entire use time. The keys have different functions in standby and during use, multifunctionality that brings further advantages to the users.
The interaction of the user with the terminal is minimal, as any function can be achieved with a single touch of the key.
Another very important characteristic of the Touch keys is that they do not get blocked, irrespective of the use frequency, which translates into long term reliability.
Call answer | Audio monitoring | Ringtone selection
When the terminal is called, the key blinks.
The talk begins with a simple touch and continues completely hands-free, during a maximum 2 min.
When the terminal is in standby mode, touching the key activates audio monitoring for 15 sec. Therefore, one can hear what goes on in front of the entrance at any time, also having available the option of bidirectional talk.
Also in stand-by mode, through a very simple procedure, the preferred ringtone can be selected from the 5 available options.
Access | Call duration setting
Access can be granted in any terminal mode – stand-by, call, talk or monitoring.
In stand-by mode, the call duration can also be set, according to preferences: 1/2/3 calls or 1 min.
Call volume | Talk volume | Mute
There are 7 available volume levels for the call and the talk, and the option of activating the silent mode call. Volume adjustments can be made during use, as well as in stand-by mode.
The silent mode is visually signaled by a red LED that is permanently on.
The auxiliary key can be used for controlling another automation: auto gate, garage door, outdoor lighting system. The ELECTRA door phone system is fitted with direct connections for such automation, feature which allows the installation to be upgraded with various additional devices.
The smart+ audio terminal can perform various functions inside the home, as it offers the possibility of directly connecting a series of
- If the doorbell button from the entrance is connected, the terminal will play the role of a doorbell.
- At the same time, an additional device for acoustic and visual signaling of the call can be connected to the terminal.
- For spacious homes, multiple additional Touch Line – 4 wires video and audio terminals can be connected, in any desired combination.
