WIFI Long Range reader 20M JT-8290W
UHF RFID Long Range reader JT-8290 could be applied in various harsh working environment for multiple protocols compatible and high speed reading. Full support the tags of ISO-18000-6C (EPC C1 GEN2) or ISO-18000-6C.Its stable reading distance is 25m (Depends on tag and environment)
Price valid only in the e-shop
2 People watching this product now!
Local Pick up (Tuuliku Tee 4)
0€
Parcel Machines (Itella Estonia)
2.99€
Parcel Machines (DPD Estonia)
6.10€
Payment Methods:
Application:
- Transportation vehicle management: Monitor and manage the transportation of vehicle and container
- Custom management: custom clearance and transit of material
- Logistic management: manage the flow of commodity, mail and package
- Manufacturing sequence: monitor parts during the whole productive process
- Device management: monitor the flow of device
| Item No. | |
| JT-8290W | RS232,WIFI,Wiegand |
| JT-8290B | RS232,TCP/IP,Wiegand |
| JT-8290A | RS232,RS485,Wiegand |
| JT-8290G | RS232,GPRS,Wiegand |
| Performance parameters | |
| Working Frequency | 902~928 MHz or 865~868MHz |
| Protocol | ISO18000-6C(EPC C1 GEN2) |
| RF power | 0~30dBm(Adjustable) |
| Software & SDK | DEMO and C#, VC, VB, Java, DELPH, etc., |
| Encryption | Can be directly encrypted, copy prevention. |
| Reading range | stable reading range 25M(Depends on tag & environment) |
| Industrial lightning protection | 6000V |
| Low temperature protection | Northeast, Northwest extremely cold region, low temperature protection |
| Frequency modulation | hopping or fixed frequency |
| Input/output port | Two-way relay output(customized), one-way trigger input |
| Antenna gain | 12dBi polarization |
| Working way | Buzzer |
| Power | 12V/3A Adaptor |
| Physical parameters: | |
| Item size | 450x450x50mm |
| Package size | 600x480x110mm |
| Net weight | 5KG |
| Shell material | ABS |
| Working temperature | -20℃~+65℃ |
| Storage temperature | -45℃~+95℃ |
| Brand |
|---|
