Description
Matrix V Reader is designed for use in online and offline access control systems.
The Matrix V reader supports simultaneous operation with long-range RFID EM Marine 125 kHz keys (for example, IL-05 ELR cards) and IL-100 (Keeloq), TOP432NA and TOP434NA remote controls (CAME standard).
The Matrix V reader is connected to the ACS controller using the iButton (1-Wire), Wiegand-26 or RS-485 protocols. There is a possibility of direct connection to a PC via the RS-485 protocol using the Z-397 Guard USB / RS-485 converter.
| goal | ACS reader |
| Working frequency | 125 kHz, 433 MHz |
| Key types | RFID (proximity), Keeloq, CAME (TOP432NA, TOP434NA) |
| Standard reader | EM Marine, Keeloq, Came |
| Reading protocol | iButton (1-Wire), Wiegand-26, RS-485 |
| RFID Reading Range (cm) | <50 (IL-05 ELR card) |
| Keeloq reading range (m) | <10 (control panel IL-100, TOP432NA, TOP434NA) |
| Keyboard | No |
| Vandal-proof housing | No |
| Waterproof dust cover | Yes |
| Key copy protection | Yes |
| Copy protection type | Keeloq Anti-clone (IL-100 remote only) |
