Product Parameter | Parameter Description |
Size | 80Lx39.5Wx24.5H(mm) |
Armature Plate Dimension | 75Lx33Wx9.4H(mm) |
Holding Force | 60kg(120Lbs) |
Input Voltage | 12VDC |
Current | 12V/120mA |
Suitable | File Cabinet, Display Cabinet |
Surface Temp | ≤+20℃ |
Operating Temp | -10~+55℃(14-131F) |
Humidity | 0~90%(non-condensing) |
Cover Finish | Anodized aluminum |
Lock Finish | Zinc |
Armature Plate Finish | Zinc |
Weight | 0.6KG |
