RZ4
| iButton (1-Wire) maximum line length (m) | 15 |
| Maximum Wiegand Line Length (m) | 100 |
| Voltage | 12 DC |
| Current consumption (mA) | 500 |
| Bleeper | Buzzer |
| Visual indication | 2 LEDs (red, green) |
| External control of LEDs and buzzer | Yes |
| Working temperature (° C) | -30 … + 40 |
| Body material | ABS polymer |
| Overall dimensions, mm) | 230х230х35 |
Price valid only in the e-shop
4 People watching this product now!
Local Pick up (Tuuliku Tee 4)
0€
Parcel Machines (Itella Estonia)
2.99€
Parcel Machines (DPD Estonia)
6.10€
Payment Methods:
The RZ4 ODM / OEM RFID Reader Board is designed to be installed as a component of your own products or inside your own enclosure. The RZ4 reader board supports EM Marine and HID ProxCard II 125 kHz keys and connects to controllers via the iButton (1-Wire) or Wiegand-26 protocol. The exact same board is installed inside the Matrix II EH reader.
The RZ4 reader board automatically detects keys that are standard for the simultaneous use of EM Marine and HID ProxCard II keys. There is a possibility of external control of light and sound indication without additional connections.
| goal | ACS reader |
| Working frequency | 125 kHz |
| Key types | RFID (proximity) |
| Standard reader | EM Marine, HID ProxCard II |
| Reading protocol | iButton (1-Wire), Wiegand-26 |
| RFID Reading Range (cm) | 6–14 |
| Keyboard | No |
| Vandal-proof housing | No |
| Waterproof and dustproof cover | No |
| Key copy protection | No |
| Synchronization of two readers | No |
| Dimensions | 12.5 × 7.5 × 2.2 cm |
|---|
