VIDEO CONNECTION BOX – 10 OUTPUTS – RJ45, DIN RAIL MOUNTING, WHITE

SKU: VCB.10DR02.ELW

find out about the price

Price valid only in the e-shop

4 People watching this product now!
Compare

Local Pick up (Tuuliku Tee 4)

0€

Parcel Machines (Itella Estonia)

2.99€

Parcel Machines (DPD Estonia)

6.10€

Payment Methods:

Connection of max. 10 terminals | DIN rail mounting

In the video connection box with 10 outputs, maximum 10 video/audio terminals can be connected.
The case is made of ABS, and the mounting can be done on DIN rail or on surface.
The connection box is fitted with short-circuit protections and, in case of failure, it isolates the respective area, keeping the rest of the
system functional.

Types of connections

The video connection box is fitted with direct connections for:

  • The main bus of the video door phone system
  • 10 video/audio terminals
  • Additional power supply, in case of installations with long cables.
Weight 0.45 kg
Dimensions 10.7 × 7.1 × 7.3 cm
Brand

Model

VCB.10DR02.ELW
Technical features

DIN rail mounting, TH 35 X 15/ 35 x 7.5; DIN 46277-3, EN50022, IEC60715 standard or surface mounting
RJ45 and screw connectors
Installation with UTP cat 5e (AWG 24) or UTP cat 6e (AWG 23) cables.
Operating voltage: 13.5 Vd.c., 2.5 Ad.c.
Range of operating temperatures: 0 … +45°C
Certification

The product is CE certified by OICPE – Certificate no. 707.
The product contains printed circuit boards certified in compliance with the UL flammability standard – Certificate no. E307311.
The product is manufactured under the ISO 9001:2008 quality management system and under the ISO 14001:2009 environment management system, certified by TÜV HESSEN – Certificates no. 73 100 4856, 73 104 4856.
