RFID TAG, PROGRAMMABLE, DARK BLUE
electraDark Grey
Click to enlarge

VIDEO SELECTION BOX – 4 INPUTS, DIN RAIL MOUNTING, DARK GREY

Compare
Add to wishlist
SKU: VSB.4DN02.ELG04 Categories: , ,
Description

Description

Connection of max. 4 video cameras | DIN rail mounting

The video selection box with 4 inputs enables the interconnection of the door phone systems with outdoor panels and/or additional external
video cameras.
Therefore, the video selection box is fitted with video signal inputs, for maximum of 4 outdoor panels (1 main + 3 additional) or maximum of 4 external video cameras.
The case is made of ABS, and the mounting can be done on DIN rail or on the surface.

Icon

VIDEO CENTRAL UNIT – 1 OUTPUT, DIN RAIL MOUNTING

1 file(s) 2.66 MB
Download

Additional information

Additional information

Weight 0.2 kg
Dimensions 10.7 × 7.1 × 7.3 cm
Brand

Model

VSB.4DN02.ELG04
Color

Dark Grey
Technical features

DIN rail mounting, TH 35 X 15/ 35 x 7.5; DIN 46277-3, EN50022, IEC60715 standard or surface mounting
Screw connectors
Recommended cables, according to distance:
4 x 0.5 mm2, for a distance of max. 100 m from the panel to the last terminal in the installation
4 x 0.75 mm2, for a distance of max. 150 m from the panel to the last terminal in the installation
UTP cat 5e (AWG 24) or UTP cat 6e (AWG 23), for a distance of max. 200 m from the panel to the last terminal in the installation
Operating voltage: 13.5 Vd.c., 2.5 Ad.c.
Range of operating temperatures: 0 … +45°C
Certification

The product is CE certified by OICPE – Certificate no. 707.
The product contains printed circuit boards certified in compliance with the UL flammability standard – Certificate no. E307311.
The product is manufactured under the ISO 9001:2008 quality management system and under the ISO 14001:2009 environment management system, certified by TÜV HESSEN – Certificates no. 73 100 4856, 73 104 4856.
